POLYVINYL CHLORIDE (PVC)

There are two types of PVC – Unplasticised (UPVC) and Plasticised.  As the properties and applications vary they will be dealt with separately.

Please Note: This page is for information purposes only. Rutland Plastics is an Injection Moulder and does not supply polymers.

UNPLASTICISED PVC

PROPERTIES

This is a cheap, rigid material which is tough under ambient conditions but it is not reliably load bearing above 60˚C.  The material has good outdoor weathering characteristics along with high clarity and flame retardance.

COLOURING

UPVC is usually clear so a wide range of colours is possible.  There are some opaque versions of the material, it can be difficult to achieve a perfect colour match with these grades due to the variation in the colour of the base material.

Finishing

UPVC can be easily machined.  Parts can be welded using a variety of methods including solvents, ultrasonic welding, hot gas and friction.

Parts moulded in this material may be painted or decorated using hot foil, silk screen printing and vacuum metallising.

CHEMICAL RESISTANCE

Mineral Acids (concentrated)Good
AlkaliGood
AlcoholFair
KetonePoor
Aromatic HydrocarbonPoor
Chlorinated HydrocarbonPoor
DetergentsGood
Oils, GreasesGood

APPLICATIONS

UPVC is used in many outdoor applications including replacement windows and doors, pipes, translucent sheeting, rainwater goods and bottles.

PLASTICISED PVC

PROPERTIES

Plasticisers are high boiling liquids which are solvents for the polymer, their addition conferring rubbery properties on the end product.  Adjustment of the type and amount of plasticisers results in a large range of flexible compositions.

The material has high abrasion resistance and good strength even at low temperature.  As with unplasticised PVC, it has high clarity and good outdoor weathering characteristics.

COLOURING

PVC is usually clear so a wide range of colours is possible.  There are some opaque versions of the material, it can be difficult to achieve a perfect colour match with these grades due to the variation in the colour of the base material.

Finishing

Depending upon the hardness of the PVC it can be .  Parts can be welded using a variety of methods including solvents, ultrasonic welding and heated tool.

CHEMICAL RESISTANCE

Mineral Acids (dilute)Good
Mineral Acids (concentrated)Fair
AlkaliGood
AlcoholFair
KetonePoor
Aromatic HydrocarbonPoor
Chlorinated HydrocarbonPoor
DetergentsGood
Oils, GreasesGood

PVC USE

Pipe Fittings31%
Windows & Doors24%
Packaging14%
Wire/Cable10%
Coated Fabric/Paper6%
Floor/Wall Covering6%
GP Sheet & Film4%
Automotive4%
Other1%

APPLICATIONS

As the flexibility can be widely varied applications can range from electric cable insulation and garden hoses to footwear and even baby pants!
